  • Full range:

    Horn loaded labyrinth: 2.0m ( 6’ 8" ) length
    Full range driver: Custom designed
    6 inch paper cone w/whizzer, Neodimium magnet
    Foam surround Voice coil dia.: 25mm
    Sensitivity: 96 db/w/m at 1khz, or mean averaged from 200hz to 2khz

    Bass:

    Sealed Isobaric chamber: 20 lit. volume.
    Bass drivers: Custom designed; 2 units per enclosure
    6” X 9” inch paper cone
    Rubber surround Voice coil dia: 25 mm
    Sensitivity ( of each driver ): 91 db/w/m
    Bass module amplification: one monobloc per enclosure
    Hypex UCD digital amps
    Max. output: 400 wpc @ 8 ohms.
    Level Control
    Continuously variable active crossover filter controls

    System:

    Loudspeaker sensitivity: 98 db/w/m.
    Nominal impedance: 8 ohms.
    Frequency response: 28 Hz to 20 Khz.
    Minimum amplification power: 2 wpc

    Dimensions:

    H x D x W : 1035mm ( 3'- 5" ) x 550mm ( 1'-9 5/8" ) x 190mm ( 7.5" )
    Weight per enclosure: 28 kg ( 62 lbs )
    Shipping weight ( 2 cartons plus palette ): 82kg ( 180 lbs )
