  • Full range:

    Horn loaded labyrinth: 2.2m ( 7" – 4") length
    Full range driver: Custom designed
    7 inch paper cone w/whizzer
    Foam surround
    Voice coil dia.: 32mm
    Sensitivity: 99 db/w/m at 1khz, or mean averaged from 200hz to 2khz

    Bass:

    Sealed Isobaric chamber: 50 lit. volume.
    Bass drivers: Custom designed; 4 units per enclosure
    7.5 inch paper cone
    Rubber surround
    Voice coil dia: 25 mm
    Sensitivity ( of each driver ): 91 db/w/m
    Bass module amplification: one monobloc per enclosure
    Hypex N-core digital amp
    Max. output: 400 wpc @ 8 ohms.

    Level Control:

    Continuously variable active crossover filter controls

    System:

    Loudspeaker sensitivity: 100 db/w/m.
    Nominal impedance: 8 ohms.
    Frequency response: 22 Hz to 20 Khz.
    Minimum amplification power: 2 wpc

    Dimensions:

    H x D x W : 1040mm ( 3'-5" ) x 730mm ( 2'-4 ½" ) x 215mm ( 8.5" )
    Weight per enclosure: 60 kg ( 132 lbs )
    Shipping weight ( cartons, plus palette ):140kg (308 lbs )
